Product Code: GRT-64X01
Manufacturer Code: 64X01
Grote's 90mm LED standalone High Beam and Low Beam headlamps along with the combination High Beam / Low Beam Bi-LED headlamp module are the perfect high-tech replacements for standard 90mm halogen headlamps. Designed to enhance driving safety while meeting the most demanding on and off-road requirements, Grote's new 90mm headlamp family makes upgrading to superior LED performance an easy decision.
Features:
90mm diameter lensMounting system with included adjustment rods designed to replace standard 90mm halogen headlampsHard-coated, high-impact polycarbonate lensCast-aluminum housing with sealed integrated connectorCompact lamp profile to fit most existing applications
- Amperage: 1.6A @ 14V - LB, 3.2A @ 14V - HB
Ingress Protection: IP69K
Connection Type: Integrated 4-pin DT connector
High/low Voltage Limits: 9V/32V
Color Temperature: 5700 K
Operating Temperature: -40°C to +85°C
Lens Color: Clear
Mounting Type: 2- and 4-point rigid, 3-point using adjustment hardware
Lumens: 650 Effective - LB, 1300 Effective - HB
Dimensions (H/W/D): 152x152x129mm
Housing Color: Black
Material Lens: Lens: Hard-coated Polycarbonate, Housing: Powder-coated Aluminum
Voltage: 9-32V
Weight: 3lb (1350 grams)
Regulations: ECE R149 Asymmetric - LH Drive/RH Traffic
Moisture Resistancy: IP69K
Package Type: Individual Box
ROHS: Yes
Watts: 23W - Low Beam, 47W - High Beam
