Product Code: MNR-66209MM
Manufacturer Code: 66209MM
FOR HARDWORKING COMMERCIAL VEHICLES: Designed to handle the demands of high mileage and severe use vehicles with cab suspensions
CONSISTENT RIDE: All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-in. reserve tube holds more fluid to improve performance (when required)
EXCEPTIONAL HANDLING: 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient and consistent control (most applications)
STRONG AND DURABLE: Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- Mounting Hardware Included: No
Extended Length (IN): 10.49
Extended Length (MM): 266.4
Lower Mount Type: Loop (Eyelet) Bushing and Sleeve
Lower Mount Type: Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 2 3/4" Sleeve OAL
Upper Mount Type: Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1 7/8" Sleeve OAL
Gas Charged: Yes
Body Diameter (IN): 2.02
Body Diameter (MM): 51.3
Compressed Length (MM): 214.6
Compressed Length (IN): 8.45
Travel Length (MM): 52.1
Travel Length (IN): 2.05
Shock Absorber Rod End Measuring Point: Center of Loop
Shock Absorber Body End Measuring Point: Center of Loop
Grade Type: Premium
Adjustable Rebound: No
Dust Shield Included: Yes
Dust Shield Material: Metal
Includes Bump Stop: No
Upper Mount Code: LS96
Lower Mount Code: LS97
Hydraulic Lockout: No
Internal Rebound Bumper: Yes
Adjustable Compression: No
Adjustable Ride Height: No
Active or Passive Suspension: Passive - Warranty: Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
