Product Code: MNR-74409MM
Manufacturer Code: 74409MM
FOR HARDWORKING TRANSIT BUSES: Designed to handle the demands of high mileage and severe use transit buses
CONSISTENT RIDE: All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/4-in. reserve tube holds more fluid to improve performance (when required)
EXCEPTIONAL HANDLING: 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore allows valve finetuning by allowing more hydraulic fluid to dissipate heat for better control
STRONG AND DURABLE: Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- Mounting Hardware Included: Yes
Extended Length (IN): 18.703
Extended Length (MM): 475.1
Lower Mount Type: Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Lower Mount Type: Stem
Upper Mount Type: Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Gas Charged: No
Body Diameter (IN): 2.75
Body Diameter (MM): 69.9
Compressed Length (IN): 12.313
Compressed Length (MM): 312.8
Travel Length (IN): 6.39
Travel Length (MM): 162.3
Finish: Painted
Shock Absorber Rod End Measuring Point: Base of Stem
Shock Absorber Body End Measuring Point: Base of Stem
Shaft Diameter (MM): 18
Internal Construction Type: Twin Tube
Grade Type: Premium
Adjustable Damping: No
Adjustable Rebound: No
Dust Shield Included: Yes
Dust Shield Material: Metal
Includes Bump Stop: No
Dust Shield Diameter (MM): 80
Dust Shield Diameter (IN): 3.15
Upper Mount Code: S6
Lower Mount Code: S6
Hydraulic Lockout: Yes
Shock Absorber Bore Size (MM): 44.5
Shock Absorber Bore Size (IN): 1.75
Internal Rebound Bumper: No
Adjustable Compression: No
Adjustable Ride Height: No
Active or Passive Suspension: Passive - Warranty: Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
- Colors: Black
