Product Code: MNR-66462MM
Manufacturer Code: 66462MM
FOR HARDWORKING COMMERCIAL VEHICLES: Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
CONSISTENT RIDE: All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
EXCEPTIONAL HANDLING: 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes
STRONG AND DURABLE: Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- Mounting Hardware Included: No
Extended Length (IN): 29.46
Extended Length (MM): 748.3
Lower Mount Type: Loop Bushing and Sleeve Mount - 20mm Sleeve ID X 1 3/4" Sleeve OAL
Lower Mount Type: Loop (Eyelet) Bushing and Sleeve
Upper Mount Type: Loop Bushing and Sleeve Mount - 20mm Sleeve ID X 1 3/4" Sleeve OAL
Body Diameter (MM): 50.8
Body Diameter (IN): 2
Compressed Length (IN): 18.13
Compressed Length (MM): 460.5
Travel Length (IN): 11.33
Travel Length (MM): 287.8
Shock Absorber Rod End Measuring Point: Center of Loop
Shock Absorber Body End Measuring Point: Center of Loop
Grade Type: Premium
Adjustable Rebound: No
Dust Shield Included: Yes
Upper Mount Code: LS75
Lower Mount Code: LS75
Adjustable Compression: No
Adjustable Ride Height: No
Active or Passive Suspension: Passive
Compressed Bumper Stop: No
Extended Bumper Stop: No
Extended Hydraulic Lockout: Yes - Warranty: Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
