Product Code: TRL-10744R
Manufacturer Code: 10744R
Features rugged stainless steel or black enameled ID barLamps are mounted on 6" or 9" centers
- Category: Identification Bar
Series: 10 Series
Warranty: 1-Year
Center Distance: 6"
Common Size: 2.5" - Housing Material: Polycarbonate
KIT: Yes
Lamp Connection: PL-10
Lens Color: Red
Lens Height: 2" - Lens Material: Polycarbonate
Lens Width 2"
Mount/Trim Color: Black
Mount/Trim Material: Steel
Mount Type: 4 Screw Bracket Mount - Number of Lights: 3
Number of Wires: 2
Packaging Type: Standard
Plug Side One: PL-10
Plug Side Two: Stripped End|Ring Terminal
Sealed/Bulb Replaceable: Sealed - Standards Met: P2
Taxonomy: Lights.Identification Bars
Total Depth: 2"
Temp. Description: Middle 10 ID BAR KIT - 6" CENTERS
Total Height: 1.45"
Total Length: 0.33" - Total Width: 16"
VMRS: 034-002-013
Weight: 0.93 lb - Fixture Shape: Round
- Mount Type: 4 Screw Bracket Mount
- Package Type: Standard
- LED Color: Red
- Lens Color: Clear
- Voltage: 12V
- Light Style: Incandescent
- SAE Class: FMVSS 108|CMVSS 108|DOT|SAE
