Product Code: TRL-30090R
Manufacturer Code: 30090R
Most advanced and cost effective 2" clearance and marker lampLEDs have no filament, therefore are not susceptible to shock and vibrationLess current draw, resulting in increased battery and alternator life while allowing more power for other vehicle requirementsSAE PC-rated for combination clearance/marker applications
- Series: 30 Series
Warranty: Lifetime
Country of Origin: ZZ
Diamond Shell (Yes/No): No
Feature Highlights: PL-10|Fit 'N Forget M/C|Kit|12 V
Housing Material: Polycarbonate
KIT (Yes/No): Yes
Lamp Connection: Fit 'N Forget M/C
Lens Height_INH: 2.24
Lens Material: Polycarbonate
Lens Width_INH: 2.24
Mount/Trim Color: Gray
Mount/Trim Material: Polycarbonate
Number of Diodes/Bulbs: 8
Number of Wires: 2
Packaging Type: Standard
Plug Side One (Simplified): Fit 'N Forget M/C
Plug Side One: Fit 'N Forget M/C
Plug Side Two: Female PL-10
Reflectorized (Yes/No): No
Sealed/Bulb Replaceable: Sealed
Standards Met: P2|P3|PC
Std Carton Qty: 1
Total Depth: 1.7
Total Height: 2.92
Total Length: 0.1
Total Width: 2.92
UNSPSC/Tariff: 25172900
VMRS: 034-004-253
Weight: 0.4 - Fixture Type: Marker & Clearance Light
- Fixture Shape: Round
- Mount Type: Flange Mount
- Lens Color: Red
- Voltage: 12 V
- Light Style: LED
