Product Code: TRL-40748
Manufacturer Code: 40748
Features high impact plastic module boxMounts in 11" x 512" holeOptional mounting gasket available to provide extra seal between module and body
- Warranty: 1-Year
Housing Material: ABS
KIT: Yes
Lamp Connection: PL-3 - Lens Height: 3.9"
Lens Material: Polycarbonate
Lens Width: 3.9"
Mount/Trim Material: PVC - Number of Lamps: 2Plug Side One (Simplified): PL-3
- Plug Side One: Right Angle PL-3
Plug Side Two: Blunt Cut
Position: Left Hand Side
Sealed/Bulb Replaceable: Sealed
Standards Met: P2|S2|I6|T - Total Depth: 2.5"
Total Height: 5.7"
Total Length: 2.1"
Total Width: 12.3"
UNSPSC/Tariff: 25172900
VMRS: 034-003-074
Weight: 3.4 lbs - Fixture Shape: Round
- Mount Type: 4 Screw Bracket Mount
- Package Type: Standard
- LED Color: Clear|Red
- Lens Color: Clear|Red
- Colors: Mount/Trim Color: Black
- Voltage: 12V
- Light Style: Incandescent
